ROWE VarioFold Compact Offline Software

ROWE Fold App LT (Standard Software)

ROWE Fold App LT is the standard software included with the ROWE VarioFold Compact and is provided free with the machine. It allows operators to fold technical drawings using pre-installed folding programs for DIN and other common formats. The app also provides system monitoring information through the USB interface, giving users access to folding system counters and usage data.

• Developed for the folding system ROWE VarioFold Compact
• Included free with the VarioFold Compact
• 12 pre-installed standard folding programs
• Fan folding options: 190/210, 185/210, 180/210, 198, 210 mm and 210 mm packet folding
• Cross folding options: 297 mm and 305 mm
• Folding system counter readings: linear feet, foldings and folded documents
• System information available through the serial USB interface

ROWE Fold App SE Software

ROWE Fold App SE and PRO are software options for the ROWE VarioFold range that expand how you control and standardise folding output. They make it easier to set up repeatable fold programmes for technical drawings, plans, and maps, with clearer control over fan and cross fold parameters than the standard panel presets. SE is ideal for teams that need flexible, consistent folding across different document formats, while PRO adds the widest adjustment range for organisations that require more specialised fold sizes and tighter control for multi-standard workflows.

• Developed for the folding system ROWE VarioFold Compact
• Includes the ROWE Fold App LT
• Definition of an unlimited number of individual folding programs
• Fan folding: up to 4000 mm (157.48")
• Cross folding: up to 2500 mm (98.43") for DIN folding
• Packet width fan folding: 180 ‐ 305 mm (7.09" ‐ 12.01"), freely adjustable in steps of 1 mm (0.04")
• Packet width cross folding: 210 ‐ 305 mm (8.27" ‐ 12.01"), freely adjustable in steps of 1 mm (0.04")
• Allocation of “Favorite” keys

ROWE Fold App PRO Software

ROWE Fold App PRO includes everything available in Fold App SE, and then extends the control range for more specialised requirements. It is designed for higher-variation workflows where you need broader adjustability for fan fold packet widths and cross fold dimensions, allowing you to build more precise programmes for different standards, internal filing requirements, and map or plan formats. If you regularly switch between document types or need to match strict downstream handling such as bundling, archiving, or binding, PRO offers the most flexibility and fine control.

• Developed for the folding system ROWE VarioFold Compact
• Includes all features of ROWE Fold App SE
• Unlimited special folding programs
• Packet width lengthwise fold: 90 ‐ 420 mm (3.54" ‐ 16.54"), freely adjustable in steps of 1 mm (0.04")
• Packet width crosswise folding: 180 ‐ 420 mm (7.09" ‐ 16.54"), freely adjustable in steps of 1 mm (0.04")
• Maximum flexibility for specialised formats such as maps or letterheads
